THE TOTAL PROCESS FLOW CHART
Aluminum Ingots
Casting
Homogeneous
Design
Mold
Extrusion
Aging
Oxidation
Electrophoresis
Dusting
Painting
Insulation
Test
Package
Product
01. CASTING PRODUCTION PROCESS
Electrolytic Primary Aluminum
Measurement
Melting furnace
Ingredients
Smelting
Slag
Artificial Stirring
The First Refining
Sampling Analysis
Component Adjustment
Artificial Stirring
The Second Refining
Slag
Sampling Analysis
Place The Insulation
Casting
Hanging Rod
Identify The Furnace Number
02. EXTRUSION PRODUCTION PROCESS
Mold Heating
Aluminum Rod Heating
Sheng Mandrel Heating
Extrusion
Water, Air-cooled Quenching
Straightening
Length Cutting
Test
Artificial Aging
Test
Oxidation Plant
Spraying Workshop
03. OXIDATION PRODUCTION PROCESS
Inspection
Blank Shelves
Degreasing
Washed With Water
Washed With Water
Alkaline Corrosion
Washed With Water
Washed With Water
Neutralization
Washed With Water
Washed With Water
Pliers Material
Anodizing
Washed With Water
Electrolytic Coloring
Washed With Water
Washed With Water
Sealing
Washed With Water
Off The S helf
Inspection
Packaging
Storage
04. ELECTROPHORESIS PRODUCTION PROCESS
Inspection
Blank Shelves
Degreasing
Washed With Water
Alkaline Corrosion
Washed With Water
Washed With Water
Neutralization
Washed With Water
Pliers Material
Anodizing
Washed With Water
Washed With Water
Electrolytic Coloring
Washed With Water
Washed With Water
Pure Water Washing
Pure Hot Wash
Pure Water Washing
Electrophoresis
Pure Water Washing
Pure Water Washing
Cold Material
Curing
Off The Shelf
Inspection
Packaging
Storage
05. POWDER COATING PROCESS
Inspection
Blank Shelves
Degreasing
Washed With Water
Washed With Water
Etching
Washed With Water
Washed With Water
Washed With Water
Washed With Water
Hexavalent Chromium
Washed With Water
Washed With Water
Washed With Water
Washed With Water
Pure Water Washing
Dried
Baking
Lower Row
Inspection
On The Pieces
Blowing Dust
Spraying
Preheating
Curing
The Next Piece
Inspection
Packaging
Storage
06. FLUOROCARBON SPRAYING PROCESS
Inspection
Blank Shelves
Degreasing
Washed With Water
Washed With Water
Etching
Washed With Water
Washed With Water
Washed With Water
Washed With Water
Hexavalent Chromium
Washed With Water
Washed With Water
Washed With Water
Washed With Water
Pure Water Washing
Dried
Baking
Lower Row
Inspection
On The Pieces
Blowing Dust
Spray primer (A, B spray …
Leveling
Spray paint (A, B spray room)
Leveling
Spray paint (A, B spray room)
Leveling
Curing
The Next Piece
Inspection
Packaging
Storage
① Wear Bar Thermal Insulation Material Process
Surface Treatment Of Aluminum Profiles…
Open Teeth (Knurled)
Wear Insulation
Rolling
Inspection
Packaging
Storage
② Casting Insulation Profile Process
Surface Treatment Of …
Pouring
Curing
Cut The Bridge
Inspection
Packaging
Storage
